The wall is normally constructed by first excavating a soil bank, followed by laying a mass concrete to form a reinforced footing. Blocks in the first course are then laid whilst the concrete is still green, with blocks lightly tapped in place. Higher slump concrete should be worked into and around in order to haunch to the first course.
Behind the blocks of the first course, a 100 - 150 mm subsoil drainage pipe lined with a non-woven geotextile shall be laid. Either or one end of the pipe shall be diverted to nearest main drain, so that water could be discharged.
Thereafter, blocks are laid one by one in stretcher bond without mortared joints, as the blocks slot into each other. As construction proceeds, suitable infill material (e.g. fine friable topsoil or sand) shall be placed in the pockets of each successive course, and backfill material (e.g. sand or graded stone) shall be compacted.
For difficult soil condition and extra surcharge from the upper slope ~ a need of heavy duty wall design ~ it may be necessary to incorporate the blocks with geotextile and increase the wall angle to achieve the safety factor.
Method of statement can be obtained on request.
Final site specific wall design must be carried out by a qualified engineer.
BETOFLOR® (French derivation of beton-concrete and flore-flora), Betotitan, Betoatlas and Betojard are internationally patented walling system developed in the contrasting landscapes of Europe and Asia by Betoconcept.
For retaining walls, the patented Betoflor unique interlocking joint and dry build system has these distinguished advantages:-
- prevention of both vertical and horizontal displacement.
- quick and simple construction.
- easy alignment.
- cost effective.
- increase real estate value.
Specification
|
BETOATLAS®
|
BETOTITAN®
|
Dimensions (w x d x h) mm
|
250 x 500 x 200
|
250 x 1000 x 200
|
Number of blocks per m2
|
20
|
20
|
Weight of empty block
|
21kg approx.
|
50kg approx.
|
Weight filled with earth
|
50kg approx.
|
90kg approx.
|
Weight of wall per m2
|
1000kg approx.
|
1800kg approx.
|
Vertical angle
|
15 degrees
|
8 and 23.5 degrees
|
Maximum height
|
Up to 10 metres
|
Up to 20 metres
|
Strong external stability
|
* HILL SLOPE PROTECTION
* LANDSCAPE REMODELLING
* SECONDARY SEA DEFENCE
* RIVER EMBANKMENT
* ACOUSTIC WALLS
* TRAFFIC CALMING
* PLANTERS AND ROCKERIES
